Lifud driver | Constant Current | Linear Dimmable | 0-10V | 8-24W | 220-240V | 25-42V
QLA: If you compare our LED Products to traditional lighting you will see that our lighting radiates less heat and has a much longer life span and a very low maintenance cost. Our products are made of quality parts and have a high energy saving level. We think quality is very important so we always make sure our products are tested and have the right certificates.
| Type |
Linear Dim. 0-10V Fixed Current |
| Model |
LF-GLD025YE |
| Max Output |
8 - 24 W |
| Dim. Functions |
0-10V/PWM/Rx Dim. |
| Input Voltage |
220- 240V |
| Output Voltage |
25V-42V |
| Output Current |
250/300/350/400/450/500/550 mA |
| Efficiency (Typical) |
86% (230 Vac) |
| PF (Typical) |
0,90 (230 Vac) |
| Working Temp. |
-30℃~+50℃ |
| Dimensions |
245*30*21 mm |
| Certificates |
CE, CB, SAA, RCM |
| Warranty |
5 Years |
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
| |
|
